Godox AD-FP Flash Projector Kit 36°
$278.95 CAD
AD-FP-36
Shape AD300Pro Light with Precise Projection Control
The Godox AD-FP Flash Projector Kit 36° turns compatible Godox-mount flashes into a compact projection system for controlled shapes, patterns, and accents. The included 36° lens provides a practical medium beam angle for portraits, product photography, and creative lighting effects in the studio or on location.
The Strobepro Difference
All Strobepro equipment comes with our in-house warranty and industry-leading support. We stock parts, we use our products, and we're here to help before and after the sale. Your AD-FP ships from Canadian inventory and is backed by our Calgary-based team.
Made for Godox-Mount AD300Pro Flashes
The AD-FP is the Godox-mount version of the Godox Flash Projector family. Godox lists it for the AD300Pro and AD300Pro II. Choose the FP-R version for compatible round-head flashes or the FP-M version for compatible square-head flashes; the projector bodies are not universal across mount types.
36° Projection Lens for Balanced Coverage
The included 36° lens balances projection size with working distance, making it a useful starting point for both pattern projection and shaped light. The Godox Flash Projector system also supports 19° and 50° projection lenses when you need a tighter or broader beam.
Four Shutter Blades for Clean Light Shaping
Integrated shutter blades let you cut the beam into controlled geometric shapes without adding another modifier. This is useful for placing a narrow highlight, building a window-style shape, or keeping projected light off areas of the scene where it is not wanted.
Rotate Gobos and Shapes Without Rebuilding the Setup
The projector uses a 360° rotatable design, so you can adjust the orientation of a projected shape or gobo while the light remains mounted. This helps keep your framing and focus consistent while fine-tuning the angle of the effect.
Expandable with Gobos, Gels, and an Iris
The AD-FP supports size M gobos, slide-in colour and diffusion gels, and the optional SP-ID iris diaphragm. The iris adjusts the diameter of a circular projection, while gels and gobos add colour, texture, and pattern control.
Real World Use
Create a window pattern behind a portrait, add a defined pool of light to a product, place a narrow highlight on a subject, or add texture to a plain background. Because the AD-FP works with compatible portable Godox flashes, it brings projection-style control to compact studio and location setups.
Specifications
- Model: AD-FP-36 Kit
- Product type: Flash projection attachment for compatible Godox-mount flashes
- Included lens: 36° projection lens
- Interchangeable lens options: 19°, 36°, and 50° projection lenses
- Light shaping: Four integrated shutter blades
- Rotation: 360° rotatable design
- Gobo compatibility: Size M gobos
- Accessory support: Slide-in colour and diffusion gels; optional SP-ID iris diaphragm
- Compatible flashes listed by Godox: AD300Pro and AD300Pro II
- Projector dimensions without lens: 134 × 134 × 165 mm (5.28 × 5.28 × 6.5 in.)
- Projector weight without lens: Approximately 712 g
- 36° lens dimensions when retracted: 64 × 65 × 65 mm (2.52 × 2.56 × 2.56 in.)
- 36° lens weight: Approximately 280 g
What's Included
- Godox AD-FP flash projector
- 36° projection lens
- Godox mount ring
- Godox SP-CF gobo holder
- Godox MLP-GS gobo set
- Carry bag
- Instruction manual
Godox AD-FP Flash Projector FAQ
Which flashes fit the AD-FP?
Godox lists the AD-FP for the AD300Pro and AD300Pro II. The FP-R is used for compatible round-head flashes, while the FP-M is used for compatible square-head flashes.
Does the AD-FP kit include a flash?
No. The AD-FP is a projection attachment kit. A compatible Godox AD300Pro or AD300Pro II flash is required and sold separately.
What does the 36° lens do?
The 36° lens provides medium projection coverage. It is a balanced choice when you want useful working distance without making the projected pattern too narrow or too wide.
Can I change the projection angle?
Yes. Godox lists 19°, 36°, and 50° projection lens options for the Flash Projector system. The 19° lens is tighter, while the 50° lens gives broader coverage.
Can I use gobos and gels with the AD-FP?
Yes. The Godox Flash Projector system supports size M gobos plus slide-in colour and diffusion gels with the appropriate holders.
Can the iris and gobo holder be used together?
No. On the Flash Projector system, the optional SP-ID iris and gobo holder use the same accessory slot, so they cannot be installed at the same time.
Does the AD-FP need separate power?
No. The AD-FP is a passive optical attachment. Flash power, triggering, and exposure control come from the compatible Godox flash and trigger system.
Can I use a camera lens on the projector?
No. Use the dedicated Godox projection lenses. Godox warns against substituting camera lenses because heat may damage them.
